Crest Type Support Grid

Heavy-Duty Packing Support (Camel Hump)

Engineered with a unique wave-like (crest) profile, this support grid provides maximum free area (≥90%) to minimize pressure drop while offering superior mechanical strength to support heavy random packing beds.

Performance

Free Area: Up to 95%
Load Rating: Calculated per Project
Anti-Fouling Surface

Construction

Integral or ^{2-Piece Split} Design
Reinforced Ribs for Stability
Material: CS, SS304, SS316L, Alloy

Engineering Service: Free Structural Calculation | Fabrication: Laser Cutting & Leveling Test | Delivery: Fast Track Available

Core Advantages

Ensuring minimal pressure drop and reliable support for deep packing beds.

^01. 95% Open Area

Wave-like crest design maximizes free area, minimizing pressure drop across the grid.

^02. Heavy Load Capacity

Reinforced ribs provide exceptional strength to support heavy ceramic or metal random packing.

^03. Split Design Option

Available in two halves for easy installation through narrow manways without cutting.

Product Gallery

Robust structural engineering and precision welding.

Manufacturing Capability

Precision fabrication for structural column internals.

Laser Cutting

Ensures accurate dimensions and smooth edges.

Structural Welding

Reinforced joints for high load-bearing capacity.

Leveling Test

Guarantees flatness to prevent packing tilt.

95%

Max Open Area

20mm

Plate Thickness

100%

Flatness Check

Technical Specifications

Standard configurations and customization options.

Material Options	Carbon Steel, SS304, SS316L, Duplex 2205, Hastelloy.
Free Open Area	90% - 95% (Depending on load requirements).
Structure Type	Integral or Two-Piece Split (for small manways).
Load Capacity	Engineered to support specific packing height and density.

Key Application Areas

Essential for supporting mass transfer media in towers.

Chemical Process Towers

Supports heavy ceramic packing in distillation columns.

Absorption & Scrubbing

Prevents collapse of packing under high liquid loads.

Refinery Columns

Robust design for high-temperature and high-pressure environments.

Biogas & Biofuel

Corrosion-resistant options for acidic biological environments.
